Scrim DN130X3600mm PTFE Dipping 550gsm Nomex Filter tube

Scrim DN130X3600mm PTFE Dipping 550gsm Nomex Filter tube
Scrim DN130X3600mm PTFE Dipping 550gsm Nomex Filter tube Scrim DN130X3600mm PTFE Dipping 550gsm Nomex Filter tube Scrim DN130X3600mm PTFE Dipping 550gsm Nomex Filter tube

Large Image :  Scrim DN130X3600mm PTFE Dipping 550gsm Nomex Filter tube Get Best Price

Product Details:
Place of Origin: MADE IN CHINA
Model Number: AR 550
Payment & Shipping Terms:
Minimum Order Quantity: 100 pcs
Price: Negotiable
Packaging Details: Pallet , Carton box,knitting bags
Delivery Time: 3 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000 pcs per day
Detailed Product Description
Material: Aramid Fiber,Nomex Fiber Scrim: Nomex/PTFE Scrim
Bag Size: Customers Demands Work Temp.: 204 Degree
Air Permeability: 15-30 M3/m2.m Application: Alloys Furnace, Asphalt Mixing, Cement
Filtration Efficiency: < 10mg/Nm3 Life: 12 Months
Treatment: PTFE Dipping And Coating
High Light:

550gsm Nomex Filter Bag


PTFE Dipping Nomex Filter Bag


Nomex Dust Filter Bag

High temperature resistance Nomex filter bag 10mg/nm3 dust emission
Nomex dust filter bag is a kind of high temperature resistance filter material which has the reasonable structure and good performance. It not only has the same advantage of the woven glass fabric, as high temperature resistance, corrosion resistance, stable size, small elongation shrinkage, high strength and so on, but also the carpet fiber is the short fiber which fineness is just about 5-7 microns. Three dimensional micron pore structure , high porosity , small filtration resistance for gas, it is a kind of high temperature filter material which with the high speed and high efficiency.

PTFE coated dust collector filter bag aluminium frame

1.The filter cloth is based on the thickness of the whole filter layer and belongs to deep filtration

2. the depth of the whole filter layer is formed from the fiber into a three-dimensional porous structure, from the inside and outside to the outside Dense, forming gradient filtering.

3. high pollution capacity, long filtration life, low pressure difference

4.Repeated cleaning, economic benefits


1) The fume and smoke treatment and particle removing system in metallurgy plant, alloy plant, steel works, moulding factories, fire-retardant factories and power stations

2) Fume filtration, tiny particle recycle and division of liquid and solid in aluminum electro analysis, tin, zinc, cooper and other rare metals

3) Smoke filtration in garbage burning, coal-feed boiler and liquidized laid boilers

4) Division of liquid, solid and tiny particle recycle in chemicals, coke, carbon, dyestuff, pharmacy and plastics

Scrim DN130X3600mm PTFE Dipping 550gsm Nomex Filter tube 0
The filter bag plays a key role in the dust-cleaning process, so it is very important to do the filter selection, which should be based on its performance and the nature of the smoke, so as to have a rational and optimized scheme.
The Factors that affecting the selection of the filter medium
The Select Indication of the Filter medium
A. Temperature
B. Chemical Property
C. Concentration of the dust content
D. Filter Gas Speed
Test Item & Test Standard

SL.No.ItemTest Standard
1Area WeightFZ/T60003-91
2Air PermeabilityGB/T5453-1997
3Tensile StrengthGB/T3923.1-2013
6Liquid RepellentGB/4745-2012

Post Treatment For Filtering Materials
Singeing, calendaring,Heat setting
Water and oil repellent
PTFE Dispersion treatment
PTFE surface Coating treatment
Fire Retardant treatment
Package detail and Delivery time
Samples delivery time : 1 ~ 2 days
Normal products : Available stock
LCL orders delivery time : 7~10 days
FCL orders delivery time : 15~20 days
Shipping way & Loading Port :
By sea / air / express
Shanghai / Ning Bo/Tianjin
Steel,Metallurgy,Cement,Carbon black,Thermal Power,Asphalt mixing, waste incineration.
Technical Service &support
Provide Solutions
Offer further technical support with extensively qualified experience
Provide Senior Technical staff for on site technical support
Professional Recommendations on dust collector operation and maintenance
Professional Supervision of filter bag installation
Laboratory analysis of the condition of used filter bags and recommended solutions for optimum performance
Analysis of filter bag life and recommendations of replenishment programs
Scrim DN130X3600mm PTFE Dipping 550gsm Nomex Filter tube 1
