550 GSM Industrial Filter Fabrics 1.8mm Thickness For Particle Removing System

I'm Online Chat Now
We always choose Austin Filter mark, High temperature Nomex air slide belt and polyester air slide for our Transport silos.

—— Lafarge cement Indo

Austin Filter is our first choice for our BF1,BF2 and BF3 gas cleaning dry filter bags, DN130X6000mm FMS filter bags is the best in China.

—— Baosteel

550 GSM Industrial Filter Fabrics 1.8mm Thickness For Particle Removing System

550 GSM Industrial Filter Fabrics 1.8mm Thickness For Particle Removing System
550 GSM Industrial Filter Fabrics 1.8mm Thickness For Particle Removing System 550 GSM Industrial Filter Fabrics 1.8mm Thickness For Particle Removing System

Large Image :  550 GSM Industrial Filter Fabrics 1.8mm Thickness For Particle Removing System Get Best Price

Product Details:
Place of Origin: Made in China
Brand Name: Austin Filter
Certification: ISO
Model Number: AR550
Payment & Shipping Terms:
Minimum Order Quantity: 50 meters
Price: Negotiable
Packaging Details: Roll form , 100 meter per roll.
Delivery Time: 10 days
Payment Terms: T/T, D/A, D/P
Supply Ability: 2000 meter per day
Detailed Product Description
Material: Aramid Fibers Weight: 450-550 Gsm
Scrim: Industrial Filter Cloth Width: Max 2200 Mm
Thickness: 1.8mm Usage: Asphalt Mixing Plant Dust Filtration
High Light:

dust collector filter cloth

,

non woven filter fabric

Aramid needle punched felt 550 gsm for dust collector bag filter making



1) Perfect high temperature repellent : the Nomex filter felt operation temperature can reach at 204 degree C, the instant temperature can reach at 240 degree C.



2) Stability size of the bag: there will be less than 1% dry shrink in 204 degree C condition.



3) Anti-Flame: The Nomex filter felt will be decomposition and oxidation in 400 degree C.the data of LOI will be 30.



4) The excellent chemical parameter: Anti-Acid and Hydrocarbons



Specifications



Compositions Aramid/Aramid scrim
Weight (g/m2) 450 500 550
Thickness (mm) 2.0 2.2 2.4
Air permeability (m3/m2·min) 21 17 14
Tensile strength (N/5 20cm) Warp >800 >800 >800
Weft >1100 >1200 >1300
Tensile Elongation () Warp <35 <35 <35
Weft <55 <55 <55
Broken strength 2.55 2.40 2.35
Working Temperature() ≤204 ≤204 ≤204

)

Short time Working temperature()

240 240 240
Anti-acid Medial
Anti-alkali Excellent
Anti-abrasion Excellent
The stability of water solution Medial
Finishing treatment Singeing, calendaring or PTFE coated



Applications:

1) The fume and smoke treatment and particle removing system in metallurgy plant
2) Smoke filtration in garbage burning, coal-feed boiler,power plant
3) Asphalt concrete mixture, cements, ceramics, building materials
4) Dust treatment, purification and collection in electronics, mining, flour and timber processing.
