White Polyester Air Slide Fabric Filter 50 Meters Length For Cement Processing

I'm Online Chat Now
We always choose Austin Filter mark, High temperature Nomex air slide belt and polyester air slide for our Transport silos.

—— Lafarge cement Indo

Austin Filter is our first choice for our BF1,BF2 and BF3 gas cleaning dry filter bags, DN130X6000mm FMS filter bags is the best in China.

—— Baosteel

White Polyester Air Slide Fabric Filter 50 Meters Length For Cement Processing

White Polyester Air Slide Fabric Filter 50 Meters Length For Cement Processing
White Polyester Air Slide Fabric Filter 50 Meters Length For Cement Processing White Polyester Air Slide Fabric Filter 50 Meters Length For Cement Processing White Polyester Air Slide Fabric Filter 50 Meters Length For Cement Processing

Large Image :  White Polyester Air Slide Fabric Filter 50 Meters Length For Cement Processing Get Best Price

Product Details:
Place of Origin: Made In China
Brand Name: Austin Filter
Certification: ISO
Model Number: AIRCO 4,5,6 made in China
Payment & Shipping Terms:
Minimum Order Quantity: 50 meters
Price: Negotiable
Packaging Details: Roll form, 50 meters per roll, Pallet
Delivery Time: 15 days
Payment Terms: T/T, D/P, D/A, L/C
Supply Ability: 500 meters per day
Detailed Product Description
Material: Polyester Spun Yarn Construction: 4 Ply Solid Weave
Weight: 4.0 Kg/m2 Width: 270,330,450,550,900mm
Air Peremabiltiy: 3.2-10 M3/m2/m Application: Cement Processing
Packing: 50 Meters Length Color: White
Name: Air Slide Fabric
High Light:

air slide belt

,

polyester conveyor belt

White Polyester Air Slide Fabric Filter 50 Meters Length For Cement Processing



Austin Industries  fluidization fabric  is ideal for the alumina transportation : many smelters are using it in their airslides. It improves alumina conveying as buffer silos, siphon smelter pots and fluidized bottom for filters.



Our quality of fabrics could be cut in any shape,plate or conical and fitted any place.







Specifications:



Raw Material =100% spun fiber polyester

Weight in average = 4000 g/m2
Thickness = 5mm
Mean Air Permeability = 400 m3/m2h @350H2O

Pressure: 2000pa for middle air resistance

4000pa for high air resistance

Breaking Strength- Warp=>6000 N/5cm X 20cm
Breaking Strength- Weft= >3000 N/ 5cm X 20cm
Breaking Elongation - warp=<5%
Breaking Elongation -weft=<5%

Max Width: 2800mm

Operating Temperature < 150 deg.C
Recommended Maximum Continues <180 deg.C
Recommended Maximum Surge = 180 deg.C



Air Slide Fabrics for all Pneumatic gravity Conveyor System i.e. Air Slide, Fluidor, Fluxo-Channel Fluid Slide, Aeration – Box, Airlift or Aerpole pumps in Sillo, Bin & Hopper.

For bulk material conveying fine crushed and ground powdered chemical mineral substances used to manufacture cement as well as any other similar powdered products.

Our “Air Slide Fabrics” have good abrasion resistance offered in 100% Synthetic qualities of polyester to withstand organic and inorganic chemicals, acids, alkalis and oxidizing agents contained in raw mix, clinker and cement.
